5920PL-07W-B70 cooling fan
| Manufacturer | NMB |
|---|---|
| Part number | 5920PL-07W-B70-D00 |
| other name | 15050PA-48Q-EA-00,5920PL07WB70D00,5920PL07WB70D00-ND,592OPL-O7W-B7O-DOO, |
| AC/DC | DC Fans |
| Fan Type | Axial |
| Size | 172 mm x 150 mm x 50 mm |
| Voltage | 48V |
| Current | 0.51A |
| PoWer | 24.5W |
| Termination | 2 wires |
| Speed (RPM) | 4000 |
| Air Flow | 300.0 CFM (8.50 m³/min) |
| Bearing | Ball |
| Shape | Rectangular |
| Series | 5920PL |
| Static Pressure | 0.909 in H2O (226.5 Pa) |
| Noise | 63.2 dBA |
| Blade_material | Plastic |
| Frame_material | Aluminum |
