AST3501-C1-AF Pro-face HMI

Category: .
  • Display Type: Color LCD
  • Display Size: 10.4″
  • Resolution: 640 x 480 pixels (VGA)
  • Display Colors: 16 Colors
  • Backlight: CCFL (User nonreplaceable parts, return system to distributor.)
  • Brightness Control: 8 Levels (Adjusted with the touch panel)
  • Contrast Control: Not applicable
  • Input Voltage: AC 100 to 240 V
  • Rated Voltage: AC 85 to 264 V
  • Rated frequency: 50/60 Hz
  • Rated frequency range: 40 to 72 Hz
  • Allowable Voltage Drop: 1 cycle or less(Voltage drop interval must be 1 second or more.)
  • Power Consumption: AC 100 V: 90 VA or less, AC 240 V: 108 VA or less
  • Cooling Method: Natural air circulation
  • Touch Panel Type: Resistive Film (analog)
  • Touch Panel Resolution: 1,024 X 1,024
  • Touch Panel Service Life: 1,000,000 times or more
  • Shipping Weight: 3 kg
